EG4 12kPV Hybrid Inverter | 48V | 12000W PV Input | 8000W Output | 120/240V Split Phase | All-In-One Solar Inverter

EG4 12kPV Hybrid Inverter

The EG4 12K is a versatile hybrid inverter designed to support grid-tied, off-grid, and battery backup solar power systems. Operating at 48V DC input, it delivers a robust continuous AC output of 8,000 watts, making it suitable for residential and commercial applications requiring reliable and efficient energy management. Featuring dual MPPT trackers for maximum solar harvest, up to 190A battery charging capacity, and expandable parallel operation supporting up to 10 units, the EG4 12kPV offers scalable power solutions. Built-in Wi-Fi and RS485 enable convenient remote monitoring, while its rugged NEMA 4X enclosure ensures durability under various environmental conditions. Certified to meet UL 1741 SB standards, this inverter provides both performance and peace of mind backed by a 5-year limited warranty.

Key Specifications

• Model: EG4 12kPV

• Inverter Type: Hybrid (Grid-Tie, Off-Grid, Battery Backup)

• Input Voltage: 48 volts DC

• PV Input Capacity: 12,000 watts

• AC Output Power: 8,000 watts continuous

• Output Voltage: 120/240 volts AC split phase

• Frequency: 50/60 Hz

• Maximum Efficiency: 97.5%

• MPPT Voltage Range: 150 to 425 volts DC

• Maximum PV Input Voltage: 500 volts DC

• Number of MPPTs: 2

• Battery Charging Current: Up to 190 amps

• Parallel Capability: Up to 10 units (80,000 watts total output)

• Monitoring: Built-in Wi-Fi and RS485 for remote monitoring

• Display: LCD touchscreen

• Certifications: UL 1741 SB, NEMA 4X, CEC listed

• Dimensions (H x W x D): 29.5 x 20.5 x 11.2 inches

• Weight: Approximately 110 pounds (50 kilograms)

• Operating Temperature Range: -25°C to +60°C

• Warranty: 5-year limited warranty
