Victron Energy Orion XS 1400 DC-DC battery charger
Victron Energy
$493.00
(No reviews yet)
Write a Review
Victron Energy
Victron Energy Orion XS 1400 DC-DC battery charger
Victron Energy Orion XS 1400 DC-DC Battery Charger – 12V to 12V | 100A | Isolated | Smart Charging
The Victron Orion XS 1400 is a next-generation isolated DC-DC battery charger designed for high-efficiency 12V to 12V charging applications. Delivering up to 100A (1400W), it supports both lead-acid and lithium batteries, making it ideal for automotive, marine, RV, and off-grid systems.
Featuring full Bluetooth connectivity for setup and monitoring via the VictronConnect app, this smart charger includes adjustable output, fully programmable charging profiles, and built-in protection features. Its fanless design ensures silent operation, while active heat management maximizes performance and longevity.
Key Specifications
• Model – Orion XS 12/12-100A (1400W) Isolated
• Charger Type – DC-DC Battery Charger
• Input Voltage – 10–17V DC
• Output Voltage – 10–15V DC (adjustable)
• Output Current – Up to 100A
• Maximum Power Output – 1400W
• Battery Compatibility – 12V lead-acid and lithium (LiFePO₄)
• Isolation – Galvanically isolated
• Charging Stages – Programmable multi-stage charge (bulk, absorption, float)
• Cooling – Passive, fanless design
• Monitoring – Bluetooth via VictronConnect App
• Protection – Overheat, short-circuit, input/output reverse polarity, undervoltage
• Dimensions – 7.2 x 4.7 x 2.9 in (182 x 120 x 73 mm)
• Weight – 2.9 lbs (1.3 kg)
• Warranty – 5 Years Manufacturer Warranty
• Enclosure – IP65-rated for dust and water resistance
• Operating Temperature – -20°C to +55°C
