Victron MPPT 75/15 Solar Charge Controller
Victron Energy
$69.51
(No reviews yet)
Write a Review
Victron Energy
Victron MPPT 75/15 Solar Charge Controller
Victron Energy BlueSolar MPPT 75/15 Solar Charge Controller
A robust MPPT solar charger for 12 V and 24 V battery systems, offering up to 15 A charging current with ultra-fast MPPT tracking, intelligent load output, and VE.Direct communication (Bluetooth via optional dongle). Perfect for RV, marine, and off-grid solar setups.
Key Specifications
• Model – BlueSolar MPPT 75/15
• Battery Voltage – 12 V / 24 V auto-select
• Max Charge Current – 15 A
• Max PV Input Voltage – 75 V
• Max PV Power – 220 W (12 V) / 440 W (24 V)
• MPPT Efficiency – Up to 98%
• Load Output – 15 A, short-circuit protected, BatteryLife intelligent disconnect
• Charge Algorithm – Multi-stage adaptive (bulk/absorption/float), temperature compensated
• Self-Consumption – 0.9 oz load on / ≤0.35 oz load off
• Communication – VE.Direct port; Bluetooth via VE.Direct dongle
• Cooling – Natural convection
• Protections – Over-temperature, reverse polarity, short-circuit, PV reverse current
• Enclosure Rating – IP43 electronic components, IP22 terminals
• Dimensions – 3.94 × 4.45 × 1.57 in
• Weight – 1.1 lb
• Operating Temperature – -22°F to 140°F (full rated output up to 104°F)
• Terminals – AWG 10 (6 mm²)
• Warranty – 5‑year limited warranty
