Victron Energy MultiPlus-II 12/3000/120-50 | 120V Inverter/Charger
The Victron MultiPlus-II 12/3000/120-50 is a multifunction inverter/charger for 12V battery systems with ESS capability. It delivers pure sine wave 120V power, a high-output charger, and a 50A transfer switch, with VE.Bus integration for monitoring and system expansion.
Key Specifications
• Model – Victron Energy MultiPlus-II 12/3000/120-50
• Battery Voltage – 12 V
• PowerControl / PowerAssist – Yes
• Transfer switch – 50 A
• Maximum AC input current – 50 A
• DC input voltage range – 9.5 – 17 V
• Output – Output voltage: 120 VAC ±2%
• Frequency – 60 Hz ±0.1%
• Continuous output power at 25°C (VA) – 3000 VA
• Continuous output power at 25°C (W) – 2400 W
• Continuous output power at 40°C (W) – 2200 W
• Continuous output power at 65°C (W) – 2000 W
• Peak power – 5500 W
• Maximum efficiency – 93%
• Zero-load power – 13 W
• Zero-load power in AES mode – 9 W
• Zero-load power in Search mode – 3 W
• AC input – Input voltage range: 90 – 140 VAC
• AC input frequency range – 45 – 65 Hz
• Charge voltage “absorption” – 14.4 V
• Charge voltage “float” – 13.8 V
• Storage mode – 13.2 V
• Max. battery charge current – 120 A
• Battery temperature sensor – Yes
• Auxiliary output – 32 A
• External AC current sensor (optional) – 100 A
• Programmable relay – Yes
• Protection – a – g
• VE.Bus communication port – For parallel, split-phase and three-phase operation, remote monitoring and system integration
• General purpose com. port – Yes, 2x
• Remote on-off – Yes
• Operating temperature range – -40 to +60°C (-40 to 140°F) (fan assisted cooling)
• Humidity (non-condensing) – max 95%
• Material & Colour – Steel, blue RAL 5012
• Protection category – IP22
• Battery connection – M8 bolts
• 120 VAC-connection – 13 mm² (6 AWG)
• Weight – 19 kg / 42 lb
• Dimensions (hxwxd) – 578 x 274 x 148 mm / 22.8 x 10.9 x 5.8 inch
• Listings – UL458
• Safety – EN-IEC 60335-1, EN-IEC 60335-2-29, CSA C22.2 107.1-16
• Emission, Immunity – EN-IEC 61000-3-2, EN-IEC 61000-3-3; IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
